Endo motor with apex locator Endo Motor X

Endo motor with apex locator Endo Motor X

A brushless electric motor is placed in the ergonomic plastic case of the endomotor, the torque is adjustable from 0.6 to 3.9N*cm. The portable device is equipped with an O-LED display, which displays all processes in real time. The operation of the device is controlled using the buttons built into the case.

The endomotor has a memory option, thanks to which the user can set and remember individual work settings (torque, speed, etc.). The presence of an apex locator integrated into the body ensures safe passage of the apex and more effective preparation of the root canal for obturation.

Endo Motor X supports the following operating modes:

• standard, cutting tool rotates clockwise;
• autoreverse, counter-clockwise rotation;
• reciprocating mode, the angle of rotation is adjustable from 30° to 340°, while the step is equal to 10° (speed adjustment is available within 150-500 rpm, the torque is limited within 0.4 to 1.0 N *cm;
• ATR mode, with adaptive function of reverse torque (rotation is clockwise, but when overloaded, the micromotor starts to rotate forward/backward, the rotation angle is: 240°/90° or 180°/90°, the rotation speed can vary within 500, 300 or 150 rpm, the torque is the same as in the reciprocal mode);
• apex locator, where you can safely measure the length of the root canal with the micromotor turned off;
• automatic shutdown of the device when not used for a long time.

The electric endomotor is powered by a built-in lithium-ion battery with a capacity of 1400mAh. The device is recharged on the base stand connected to the charger. The base is connected to standard power grids with a voltage of 110-220V through Micro USB and a power adapter.

The reduced gear ratio of the endomotor tip 16:1 allows you to develop the speed of rotation from 150 to 800 rpm.

Delivery set:

• endomotor - 1 pc.;
• angular reducing tip with 16:1 reduction - 1 pc.;
• basic stand with an integrated charging station - 1 pc.;
• lubricating nozzle - 1 pc.;
• apex locator measuring wire - 1 pc.;
• file holder - 4 pcs.;
• destructive electrode - 2 pcs.;
• measuring probe - 2 pieces;
• spare electrode - 1 pc.;
• network adapter - 1 pc.;
• instruction;
• packaging.
